Standard&ProtocolIEEE 802.3/u/x/ab
Interface5* 10/100/1000Mbps auto-negotiation RJ45 ports, auto MDI/MDIX
Transmission Media10BASE-T: Cat.3 or Above
100BASE-TX/1000BASE-T: Cat.5, Cat.5e or Above
Forwarding Rate10Mbps: 14880pps
100Mbps: 148800pps
1000Mbps: 1488000pps
LED5*10/100/1000Mbps Link/Act LEDs
1*power LED
FeaturesStore-and-forward mechanism
Auto-learning and auto-aging MAC address
Switching capacity of 10Gbps
Power Input100-240V~50/60Hz
Power Output5V/0.6A
ConsumptionStandby: 0.5W Maximum：2.5W（220V/50Hz）
Dimension96*66*23mm
Operation Temperature0℃~45℃
Operating Humidity10%~90% non-condensing
Storage Temperature-40℃~70℃
Storage Humidity5%~90% non-condensing
